LP-24-USB2.0/3.0 Industrial Circular Waterproof Aviation Plug Data Connector

Lightning-Fast Connections, Data Transfer at the Speed of Light

Video

Product Size

M24

Pin

Single Pin

IP Grade

IP68 / IPX9K

Rated Current

1.8A

Rated Voltage

5V

Product Series

LP

Wiring Type

Soldering

Interface Type

USB

Mating Cycles

≥500 times
Complies with product certification:
UL
TUV
CQC
CE
RoHS
REACH
System certification:
IATF 16949
ISO 13485
ISO 9001
ISO 14001
ISO 50001
ISO 45001
Specifications
橱窗图-1
橱窗图-3
橱窗图-2

USBFour hole suit

USB Plug

USB Cable Plug

2-爆炸图 2-爆炸图

LP Series IP68 Waterproof USB Connector

Product Advantage

3-优势图 3-优势图
Uncompromising IP68 Waterproofing, Reliable Imported Plastic Build, Tailored Socket Options, Choose Your USB Speed, Rapid One-Hand Connection, and Green-Plated for a Sustainable Future.
4-特点图

IP68 flagship-level waterproof, confident in water environments

Advanced waterproofing with IP68 rating, reliably protects against water ingress in outdoor, industrial, and medical applications

5-特点图

Imported quality plastic, performance so powerful

Utilizing imported plastic materials from SABIC, offering enhanced stability, superior durability, and reliable performance in complex and harsh environments

6-特点图

Rapid transmission, fast data transfer, USB2.0 & USB3.0 optional

High-speed USB interface for stable and fast data transmission; available in USB 2.0 and USB 3.0 versions to meet diverse user needs in performance and cost-effectiveness

7-特点图

One-hand plug and lock, both quick and secure

Features a push-button snap-in connection design, enabling quick and secure mating and locking of connector plugs and receptacles with single-handed, one-press insertion and removal

Family series

08-家族图

Product Dimension

LP24-dimension-en

Product Parameter

Model: LP-24 Pin: USB2.0/USB3.0
IP Rating: IP68 / IPX9K Rated Current: 1.5A / 1.8A
Rated Voltage: 5V AC Withstand Voltage: 100V AC
Contact Resistance Max: 30mΩ Insulation Resistance Min: 100MΩ
Contacts: / Durability: ≥500 times
Wire Spec Max: 28AWG Wire range: ≤Φ13.5mm
传输速率: 480 Mbps / 5Gbps Maximum temperature rise: 30k
Work Temperature: -25°C~+85°C(Plastic)

Please note: To access more detailed specifications and parameter tables, please proceed to the Download Center for viewing and downloading.
