When you get the connector and prepare to use it, there is one step that cannot be avoided, which is wiring. Except for the integrated cable assembly, other connectors basically need to be wired. Of course, there are many ways to wire. Soldering wiring can be said to be a widely used and popular wiring method in the market. As a commonly used wiring method, do you have a clear understanding of its advantages and usage essentials?
What are the advantages of using soldering wiring for connectors?
|
Advantages of Industrial Connector Soldering Wiring |
|
|
Wiring is more secure |
Soldering connections provide stable electrical contact, reducing the risk of poor contact |
|
Good vibration resistance
|
Soldered joints are more stable in vibrating environments |
|
Small footprint |
Soldering connections usually take up less space than other connection methods, making them suitable for compact designs |
|
Reduced maintenance |
Fusion is more stable after soldering, and soldered joints usually require less maintenance and inspection |
Recommended products BD series: Sharing of wiring tips for soldering wiring
BD series soldering wiring, these points are very important
Soldering wiring operation essentials
When stripping the wire, you must control the strength and peel off the outer skin without damaging the metal core of the wire;
Strictly follow the soldering operating procedures, and strive to keep the soldering temperature within 380°±40°;
The soldering time at each point should not exceed 3 seconds to avoid burning the insulator;
After soldering, check the soldering points to ensure that the soldering is even and firm;
Use a hot air blower to heat the heat shrink tube to protect the soldered joints.
The BD series industrial waterproof connector is an exclusive innovative product that has won the German Red Dot Design Award and the "Shenzhen Enterprise Innovation Record" double award. It adopts a new design that combines an original streamlined body and a hollow arc back top, achieving a new level of integration between industrial products and artistic aesthetics. This series of connectors with soldering wiring adopts soldering wiring, and the soldering point has high strength, which is more reliable and strong. In long-term use or in a vibration and impact environment, there will be no problems such as breakage or poor contact.
As a high-end flagship connector, the BD series has both soldering and screw connections. In addition, it has comprehensive functions, including power, signal (PIN, RJ45, optical fiber) and data (USB, HDMI) connections, which can meet the multiple technical requirements of different scenarios and different devices for connection.
One of the recommended industries: outdoor security monitoring
Outdoor security monitoring has become a technological means of protecting safety in outdoor places such as traffic roads, squares, airports, and communities. Outdoor security monitoring equipment will face water intrusion in the form of rainy days and humid air, as well as corrosion from acidic substances such as sulfur dioxide in the air. Therefore, the connection responsible for providing power for outdoor security monitoring is basically an industrial-grade connector.
In the connection solution for providing power input for outdoor security monitoring, the BD series power connector adopts soldering wiring method, which makes the connection more firm and strong. There is no need to worry about the connection being interrupted or failed due to loose or broken wiring.
Of course, adhering to the consistent advantages of the BD series, it also has the characteristics of high waterproof (IP68 protection level), corrosion resistance (salt spray test time ≥ 48H), high and low temperature resistance (metal type: -40℃~85℃; plastic type: -25℃~85℃), flame retardant, etc., which meets the technical requirements of outdoor security monitoring for connector reliability and safety. In addition, its snap-on plug-in and quick operation advantages are also very bright, which is convenient for high-altitude quick installation and connection. In short, this industrial-grade connector with a streamlined appearance and artistic beauty is both internal and external, and has outstanding performance.
At present, this product is also widely used in many fields such as automation equipment, electronic equipment, new energy, electromechanical equipment, mechanical equipment, instrumentation, ships, vehicle-mounted equipment, medical equipment, security, LED display, etc.
